SIEMENS 100mA MULTIMOBIL 2.5 X RAY MACHINES
SPECIFICATIONS MULTIMOBIL 2.5 is an operator friendly X-ray with a 2.5 kW high frequency power generator, which ensures that only a film effective dose is produced over the entire duration of the exposure while suppressing the unwanted skin dose. It has set a new standard among high frequency generators by delivering consistent output even when the input power supply voltage falls to a value as low as 170 volts or even when the supply rises to a high of 265 volts. • Besides radiography in patient wards and in operating rooms, it can be used as a stand-alone X-ray workstation, sports medicine and veterinary medicine. • Latest technology from the pioneers in X-rays with improved image quality and wide range of radiography applications • High dose yield and low patient dose • Highest reproducibility of exposures with sharp images • Compact and functional design with good ergonomics and consistent performance under extreme line conditions • Operator friendly, high mobility and easy to maneuver
SIEMENS 300 mA X RAY MACHINES HIGH FREQUENCY
SPECIFICATIONS: TECHNICAL SPECIFICATIONS Equipment Name: X Equipment Name: X Equipment Name: X-Ray Machine With Table 300mA Ray Machine With Table 300mA I X-RAY GENERATOR RAY GENERATOR RAY GENERATOR 1. Type : Full wave rectified 2. Max KVp : 125 3. Max mA: 300 4. Should have 300 mA at 100KVp. II X-RAY TUBE RAY TUBE RAY TUBE 1. Type : Rotating anode 2. Focal spot: Dual 1.2x1.2mm and 2 x 2mm 3. Anode heat capacity : 115KHU 4. Anode speed: 2800 RPM at 50 Hz. III RADIOGRAPHY RADIOGRAPHY RADIOGRAPHY 1. KV range : 40 – 125 2. mA range : Small focus - 80 to 160 mA 3. Large focus- 160 to 300 mA IV CONTROL PANEL CONTROL PANEL CONTROL PANEL
SIEMENS 500mA HELIOPHOS-D X RAY MACHINES
TECHNICAL SPECIFICATIONS Equipment Name : Equipment Name :X-Ray Machine 500mA With Table Ray Machine 500mA With Table X-RAY GENERATOR RAY GENERATOR RAY GENERATOR 1. Type : Full wave rectified 2. Max KVp: 125 3. Max mA: 500 4. Should have 500mA at 100KV and 320mA at 125KV. X-RAY TUBE RAY TUBE RAY TUBE 1. Type : Rotating anode 2. Focal spot : Dual 1.2x1.2mm and 2 x 2mm 3. Anode heat capacity: 240KHU 4. Anode speed: 2800 RPM at 50 Hz. RADIOGRAPHY RADIOGRAPHY 1. KV range: 40 – 125 2. mA range: Small focus- 80 to 160 mA 3. Large focus- 160 to 500 mA CONTROL PANEL CONTROL PANEL 1. Digital display of all radiographic parameters 2. Major and minor KVp control. 3. Electronic timer with range of 0.01 to 5 sec in at least 24 steps. 4. Automatic tube over load protection. 5. Line voltage compensator for coarse and fine adjustment. MECHANICAL SPECIFICATIONS MECHANICAL SPECIFICATIONS 1. Floor to ceiling tube stand 2. Fully counter balanced 3. Easy to move and handle 4. Light beam diaphragm collimator. 5. One pair of high voltage cables at least 6 meters long. 6. Tube head should be rotated 360 deg.
SIEMENS 800MA FLUOROSCOPY
SPECIFICATIONS: 800MA with IITV and fluoroscopy - 2units Specifications: Digital unit High frequency generator with 80kW and 1000mA Maximum mAs > 500mAs. Remote controls for table movements, etc. Suitable for general radiography (including chest x-ray) and fluoroscopy Pulse fluoroscopy Fluoroscopy with automatic spot film device High-capacity x-ray tube with two focal spots – 1. Not >0.6mm 2. Not >1.2mm Heat capacity – minimum 400 kHU Floating table top Table tilt +90o to -17o IITV 12” or more Camera 1K x 1K pixel (1Mega pixel) 18” Monitor with trolley in examination room and another 18” monitor in console room. Vertical Bucky with stand DICOM send, print and storage with cine loop memory Stabilizer for the entire equipment AERB type approval Minimum support for ten years Tube and generator from same manufacturer Lead glass of suitable size Optional - DSA
