SPECIFICATIONS
Dimensions:
Patient unit: 9.5″ (W) x 14.6″ (D) x 9.4″ (H)
User interface: 17.0″ (W) x 15.9″ (D) x 12.8″ (H)
Weight: Approx. 52.9 lbs
Ventilation Modes: Controlled
Patient Range: Large/Medium/Small Animal
Classification: IEC60601-1/EN60 601-1 Type B
Method of Triggering: Flow and Pressure
Flow Range: 0.1 ml/s – 3 l/s
Power Supply: 100, 120, 220, and 240 VAC 10%, 50-60Hz
Alarms: Airway Pressure (Upper): 15-120 cm H2O
High Continuous Pressure: Set PEEP-level +15 cm H2O for more than 15 seconds.
O2 concentration: Set value 6%. Lower alarm limit cannot go below 18% or exceed 90%.
Expired Minute Volume (Upper Alarm Limit): Adult/Pediatric Range: 0-60 l/min, Neonate Range: 0-6 l/min.
Expired Minute Volume (Lower Alarm Limit): Adult/Pediatric Range: 0.3-40 l/min, Neonate Range: 0.06-4 l/min.
Apnea: Adult: 20 s. Pediatric: 15 s. Neonates: 10 s.
SPECIFICATIONS
Patient Range Selection – Adult/Pediatric/Neo-natal h Supported and Controlled Ventilation Modes h User adjustable trigger sensitivity h Automatic Switch from Volume Support to Pressure Regulated Volume Control if patient stops breathing h Extensive Flow range 0.1 – 3000 ml/s h Automatic Emergency battery backup h 100 % oxygen breaths for suction procedures h Informative alarm and message centre h Flexible positioning around patient h Customisable respiratory patterns for fully flexible therapy h Set parameter guide h Auto mode available in 300A
Graphics Display (Optional)
Key Features
h Multiple display facilities h User-customisable data presentation h Context sensitive dialogues h 3,6,12,24 hour trend displays h Calculation of lung mechanical parameters h Single knob Icon driven control h Clear non reflexive display
