SIEMENS SIREMOBIL COMPACT L FEATURES
Versatility
The capabilities and performance of SIREMOBIL® Compact have established it as a reliable, versatile & economical mobile C-arm designed to meet the full requirements of today’s surgery. Whether used in traditional applications like orthopedics, or in the growing areas of vascular intervention, gastrointestinal surgery or minimally invasive procedures, SIREMOBIL Compact provides advanced features, thoughtful design and Siemens’ quality.
Compact Size
Transportability and maneuverability are optimized with its small footprint and the extended, Counterbalanced C-arm design. The system features a streamlined user interface for fast, efficient and easy operation.
Image Quality
The SIREMOBIL brand name is known for its superior imaging components, and SIREMOBIL Compact carries on the legacy. While image quality is maximized, all operating modes are optimized toward dose savings.
SPECIFICATIONS
Product: C-Arm Image Intensifier
Models/Ratings: HF 49/ HF 49R (3.5 / 6 KW)
Series : HF49 / HF49R
Allengers high frequency C Arm’s are incorporated using the latest state-of-the-art “High Frequency Technology”, in which there is minimal production of non useful/harmful X-Rays i.e. almost close to zero leakage radiation in this c arm machine.
Special Features
- Back-up circuitry for enhanced performance and reliability
- Feature touch control panel for ease of operation and disinfection
- Automatic Brightness Stabilizer (ABS)- to enable one to see the best image
- Thermal Safety of tube head monoblock
- Full compatibility with ESWL
- Iris collimator with/without parallel shutter (Optional)
- Laser centering device (Optional)
- Dose arena product meter (optional)
- After sale service- lightening response with a solution
- DIP-IQ memory (optional)
TECHNICAL SPECIFICATIONS OF C-ARM MACHINE Following are the minimum requirements. Products offered must meet these parameters herein. Sr. No. Technical specifications/ composition of tender enquiry Compliance on each parameter with detailed substantiation how the offered product meets the requirement. (Simply writing as YES/ Complied/ As per BIS/CE/ISO terms is not allowed) Remark s, if any 1. Mechanical motion requirements for C-Arm: a. Motorized Vertical travel: Minimum 400 mm or more b. Horizontal travel: 220 mm or better C, Rotation of C-arm: +/- 270 deg. or more d. Pivotal rotation: 12.5 deg. or more e. Orbital rotation: minimum 120 deg. (90 deg. to minimum -30 deg.) or better f. Depth / Radius of C-arm: 650 mm or better g. Free space between Image Intensifier & X-ray tube: Minimum 750 mm or more h. Source to Image intensifier distance (SID): 880 mm or more j. Total width of C-arm: Maximum 800 mm or less 2. Collimator:- Iris Collimator 3. The C-arm should have facility of locking the C-arm movements with easy to turn handle on control unit. Rear wheels must be freely movable for easy to turn handle on control unit. Rear wheels must be freely movable for easy positioning of the complete C-arm around the OT table. 4. Image Intensifier should have at least triple field 9” input diameter offering resolution and contrast ratio (25:1 or better) 5. TV Camera: Ultra Compact CCD camera or camera with CMOS or advanced CMOS sensor with high No of pixels (> 450000) and video band width (at least 20 MHz of better) along with 2 Nos. Medical grade 17” or more 625 lines 100 Hz flicker free TV monitors on separate monitor trolley with facility to rotate the image continuously.
X-Ray System: Specialty Packages Available
Extended processing.
Vascular functions.: Extended vascular functions.
Cardiac Pulsed functions.
Generator: 80 kHz High frequency.: 7.5 kW full-wave.
Up to 120 kVp. | Up to 60 mA for radiographic film exposures.
Continuous fluoro boost mode up to 20 mA. | Pulsed fluoro mode.
Pulsed fluorography mode up to 60 mA.
Full power from outlet:
50 Hz or 60 Hz. | 100V-20A to 240V-10A.
X-Ray Tube | Rotating anode X-ray tube. | Focal spots: 0.3 mm and 0.6 mm.
Anode heat capacity: 300,000 HU. | Anode cooling rate: 70,000 HU/min. | Housing heat capacity: 1,900,000 HU.
